Boeing 777-300 (773) [Japan Domestic Flights]

Only representative aircraft types are listed.
Departure/arrival times, flight No., aircraft type, equipment and operating airline are subject to change without prior notice.

Back to List

514 seats

Seatmap Information

This is the seat map for the 514-seat Boeing 777-300.
There are 21 Premium Class and 493 Economy Class seats. Seat rows are numbered from 1 to 58.
Emergency exits are located on both sides at the front of the cabin, both sides of row 10, both sides behind row 28, both sides in front of row 44, and both sides of row 58.
Premium Class seats are in rows 1 to 3.
The seat layout from left to right for these rows is A, C, aisle, D, F, G, aisle, H, K. Armrests are non-movable for all of these seats. Shared monitors are installed in front of row 1.
Economy Class seats are in rows 5 to 58.
The seat layout from left to right for rows 5 to 9, 14 to 28, 30 to 42, and 44 to 52 is A, B, C, aisle, D, E, F, G, aisle, H, J, K. The seat layout from left to right for rows 10 and 58 is D, E, F, G. The seat layout from left to right for rows 11 and 12 is A, B, C. The seat layout from left to right for row 13 is A, B, C, aisle, D, E, F, G. The seat layout from left to right for rows 29 and 43 is A, B, C, aisle, H, J, K. The seat layout from left to right for rows 53 to 57 is A, C, aisle, D, E, F, G, aisle, H, K. All seats in row 11 and row 29, and seats A, B, C, H, J, K in row 44 are emergency exit row seats. Armrests are non-movable for all seats in rows 5, 11, 29, and 44; seats D, E, F, and G in rows 13 and 30; and seats H, J, and K in row 14. Seats A and K in rows 8, 24, 29, and 44 do not have a window. Shared monitors are installed in front of rows 5, 29, and 44, in front of seats A, B, and C in row 11, in front of seats D, E, F, and G in rows 13 and 30, and in front of rows 20, 24, 38, and 53.
A wheelchair-accessible lavatory is located behind seats H, J, and K in row 14. A lavatory equipped with a diaper changing table is located in front of seats H, J, and K in row 14; two are located in front of seats D, E, F, and G in row 30; and two are located behind row 58. A lavatory is located in front of seats A and C in row 1.
Galleys are located at the front of the cabin, in front of row 13, behind row 42, and at the back of the cabin.

Seat Details

Premium Class

Premium Class Seat Details

ANA Wi-Fi Service
Wireless Entertainment
PC Power
USB Port

Economy Class

Economy Class Seat Details

ANA Wi-Fi Service
Wireless Entertainment

Spec

Aircraft for Japan Domestic Flights

Information	Details
Seats	514 seats (21 seats)
Overall Length	73.9 m
Wing Span	60.9 m
Tail Height	18.5 m
Typical Cruise Speed	890 km/h
Cruising range	3,800 km
Maximum operation altitude	13,100 m
Maximumtake off weight	234.0 ton
Engines	PW4090
Thrust of engine	40,910 kg X 2
Maximum Fuel Capacity	171 kl

* The number inside the parentheses ( ) indicates the number of Premium Class seats.
