Seat Map of Boeing 787-8

Seat Map of Boeing 787-8 (788)

On this page, you will find seat map information on the Boeing 787-8 (788)

aircraft. For further details on seats, please go to the in-flight service page and select the class and aircraft type.

240 Seats

Legend of Seat Map
Seat Map of Boeing 787-8 (240 seats)

Seat Map Information

There are 42 Business Class and 198 Economy Class seats.

Seat rows are numbered from 1 to 34.

Emergency exits are located on both sides at the front of the cabin, both sides behind row 4, both sides in front of row 23, and both sides at the back of the cabin.

Business Class seats are in rows 1 to 7.

The seat layout from left to right is A, C, aisle, D, G, aisle, H, K.

All seats come with tables. Armrests are non-movable for all of these seats.

Monitors are installed in front of rows 1 and 5.

Economy Class seats are in rows 12 to 34.

The seat layout from left to right for row 12 is A, B, C, aisle, H, J, K.

The seat layout from left to right for rows 13 to 32 is A, B, C, aisle, D, F, G, aisle, H, J, K.

The seat layout from left to right for row 33 is A, C, aisle, D, F, G, aisle, H, K.

The seat layout from left to right for row 34 is A, C, aisle, D, F, G. Seats 23A, B, C, H, J, and K are emergency exit row seats.

Armrests are non-movable for all seats in rows 12 and 23 and seats 13D, F, and G. Seats 23A and 23K do not have a window.

Monitors are installed in front of rows 12 and 23.

A wheelchair-accessible lavatory equipped with a multi-function bidet and diaper changing table is located behind seats 22A, B, and C. Lavatories equipped with a multi-function bidet and diaper changing table are located behind seats 4H and 4K and behind seats 34D, F, and G. Lavatories equipped with a multi-function bidet are located in front of seats 1A and 1C, behind seats 4A and 4C, and behind seats 22H, J, and K. A lavatory is located behind seats 34A and 34C.

Galleys are located at the front of the cabin, behind row 22, and at the back of the cabin.

A bar is located behind row 4.

Spec
Information Details
Seats 240 seats
Overall length 56.7 m
Wingspan 60.1 m
Tail height 16.9 m
Typical cruise speed 910 km/h
Cruising range 12,020 km
Maximum operation altitude 13,100 m
Maximum takeoff weight 212.0 ton
Engines Trent 1000
Thrust of engine 28,940 kg x 2
Maximum fuel capacity 126 kl
Notes:
  • Please note that only representative arrangements are shown on this seat map.
  • Scheduled aircrafts are subject to change without prior notice.

184 Seats

Legend of Seat Map
Seat Map of Boeing 787-8 (184 seats)

Seat Map Information

There are 32 Business Class, 14 Premium Economy, and 138 Economy Class seats. Seat rows are numbered from 1 to 35.

Emergency exits are located on both sides at the front of the cabin, both sides behind row 5, both sides in front of row 25, and both sides at the back of the cabin.

Business Class seats are in rows 1 to 9.

The seat layout from left to right for rows 1, 3, 5, 7, and 9 is A, aisle, D, G, aisle, K. The seat layout from left to right for rows 2, 4, 6, and 8 is C, aisle, F, aisle, H. All seats come with tables. Armrests are non-movable for all of these seats.

Premium Economy seats are in rows 15 and 16.

The seat layout from left to right is A, C, aisle, D, F, G, aisle, H, K. Armrests are non-movable for all of these seats. Monitors are installed in front of row 15.

Economy Class seats are in rows 20 to 35.

The seat layout from left to right for rows 20 to 33 is A, B, C, aisle, D, F, G, aisle, H, J, K. The seat layout from left to right for row 34 is A, C, aisle, D, F, G, aisle, H, K. The seat layout from left to right for row 35 is A, C, aisle, D, F, G. Seats 25A, B, C, H, J, and K are emergency exit row seats. Armrests are non-movable for all seats in rows 20 and 25. Seats 25A, 25K, 32A, and 32K do not have a window. Monitors are installed in front of rows 20 and 25.

A wheelchair-accessible lavatory equipped with a multi-function bidet is located behind seats 24D, F, and G. Lavatories equipped with a multi-function bidet and diaper changing table are located behind seat 5A and behind seats 24D, F, and G. Lavatories equipped with a multi-function bidet are located in front of seat 1A, behind seat 5K, behind seats 24A, B, and C, and behind seats 24H, J, and K.

Galleys are located at the front of the cabin, behind row 5, and at the back of the cabin.

A bar is located behind row 5.

Spec
Information Details
Seats 184 seats
Overall length 56.7 m
Wingspan 60.1 m
Tail height 16.9 m
Typical cruise speed 910 km/h
Cruising range 14,740 km
Maximum operation altitude 13,100 m
Maximum takeoff weight 227.9 ton
Engines Trent 1000
Thrust of engine 31,660 kg x 2
Maximum fuel capacity 126 kl
Notes:
  • Please note that only representative arrangements are shown on this seat map.
  • Scheduled aircrafts are subject to change without prior notice.

169 Seats

Legend of Seat Map
Seat Map of Boeing 787-8 (169 seats)

Seat Map Information

There are 46 Business Class, 21 Premium Economy, and 102 Economy Class seats. Seat rows are numbered from 1 to 31.

Emergency exits are located on both sides at the front of the cabin, both sides behind row 5, both sides in front of row 20, and both sides at the back of the cabin.

Business Class seats are in rows 1 to 13.

The seat layout from left to right for rows 1, 3, 5, 7, 9, 11, and 13 is A, aisle, D, G, aisle, K.

The seat layout from left to right for rows 2, 4, 6, 8, 10, and 12 is C, aisle, F, aisle, H.

All seats come with tables.

Armrests are non-movable for all of these seats.

Premium Economy seats are in rows 15 to 17.

The seat layout from left to right is A, C, aisle, D, F, G, aisle, H, K.

Armrests are non-movable for all of these seats.

Monitors are installed in front of row 15.

Economy Class seats are in rows 20 to 31.

The seat layout from left to right for rows 20 to 29 is A, B, C, aisle, D, F, G, aisle, H, J, K.

The seat layout from left to right for row 30 is A, C, aisle, D, F, G, aisle, H, K.

The seat layout from left to right for row 31 is A, C, aisle, D, F, G. Seats 20A, B, C, H, J, and K are emergency exit row seats.

Armrests are non-movable for all seats in row 20. Seats 20A, 20K, 28A, and 28K do not have a window.

Monitors are installed in front of row 20.

A wheelchair-accessible lavatory equipped with a multi-function bidet and diaper changing table is located in front of seats 20D, F, and G.

A lavatory equipped with a multi-function bidet and diaper changing table is located behind seat 5A.

Lavatories equipped with a multi-function bidet are located in front of seat 1A, behind seat 5K, in front of seats 20A, B, and C, and in front of seats 20H, J, and K.

Galleys are located at the front of the cabin, behind row 5, and at the back of the cabin.

A bar is located behind row 5.

Spec
Information Details
Seats 169 seats
Overall length 56.7 m
Wingspan 60.1 m
Tail height 16.9 m
Typical cruise speed 910 km/h
Cruising range 14,800 km
Maximum operation altitude 13,100 m
Maximum takeoff weight 227.9 ton
Engines Trent 1000
Thrust of engine 31,660 kg x 2
Maximum fuel capacity 126 kl
Notes:
  • Please note that only representative arrangements are shown on this seat map.
  • Scheduled aircrafts are subject to change without prior notice.
