Boeing 767-300 (76P/763) [Japan Domestic Flights]

Only representative aircraft types are listed.
Departure/arrival times, flight No., aircraft type, equipment and operating airline are subject to change without prior notice.

* As the aircraft code varies by the boarding date, it is shown as flights boarding until May 18, 2026 or flights boarding on/after May 19, 2026.

Back to List

270 seats

Seatmap Information

This is the seat map for the 270-seat Boeing 767-300.
There are 10 Premium Class and 260 Economy Class seats. Seat rows are numbered from 1 to 2 and from 5 to 43.
Emergency exits are located on both sides at the front of the cabin, both sides behind row 20, and both sides on row 43.
Premium Class seats are in rows 1 and 2.
The seat layout from left to right is A, C, aisle, D, aisle, H, K. Armrests are non-movable for all of these seats. Shared monitors are installed in front of row 1.
Economy Class seats are from row 5 to 43.
The seat layout from left to right for rows 5 to 18 and 21 to 41 is A, C, aisle, D, F, G, aisle, H, K. The seat layout from left to right for rows 19 to 42 is A, C, aisle, D, F, G. The seat layout from left to right for row 20 is A, C. The seat layout from left to right for row 43 is D, F, G. Seats A, C, H, and K in row 21 are emergency exit seats. Armrests are non-movable for all seats in rows 5 to 21. Seats A and K in rows 16 and 17 do not have a window. Shared monitors are installed in front of row 5; in front of seats D, F, G, and the aisle in row 21; and in front of the aisle in rows 10, 16, 28, 33, and 38.
A wheelchair-accessible lavatory is located behind seats H and K in row 18. A lavatory equipped with a diaper changing table is located in front of seats H and K in row 18; one is located in front of seats D, F, and G in row 21; and one is located behind seats H and K in row 41. A lavatory is located in front of seats A and C in row 1.
Galleys are located at the front of the cabin, in row 20, and at the back of the cabin.

Seat Details

Premium Class

Premium Class Seat Details

ANA Wi-Fi Service
Wireless Entertainment
PC Power
USB Port

Economy Class

Economy Class Seat Details

ANA Wi-Fi Service
Wireless Entertainment
USB Port

Spec

Aircraft for Japan Domestic Flights

Information	Details
Seats	270 seats (10 seats)
Overall Length	54.9 m
Wing Span	47.6 m
Tail Height	15.9 m
Typical Cruise Speed	880 km/h
Cruising range	3,370 km
Maximum operation altitude	13,100 m
Maximumtake off weight	131.0 ton
Engines	CF6-80-C2B2
Thrust of engine	23,500 kg X 2
Maximum Fuel Capacity	46 kl

* The number inside the parentheses ( ) indicates the number of Premium Class seats.
